Workshop on DMR Hotspots: Special Interest Group 20 August
On 20 August, from 1pm to 3pm, the Special Interest Group for DMR and Hotspots met at Mike ZL1AXG QTH.
This was an opportunity to share knowledge about DMR Hotspots. Zane ZL1CZ gave a brief talk, and Mike ZL1AXG demonstrated his 3 hotspots. One was receiving Brandmeister TG91 and the other ZL TRBO on the DMR+ network.
